Price ₹
1,40,000.00
₹1,65,000.00
| General Details: | |
| Spindle Travel | 250 mm |
| Drilling Capacity in Mild Steel | 40 mm |
| Maximum Drilling Radius | 980 mm |
| Spindle Speeds | 88-2600 RPM |
| Elevating Motor | 0.5 HP |
| Drive Motor | 2 HP |
| model | YRD-40 |
CAPACITY :
Drilling Capacity : 40/45 mm (MS/CI)
Column Diameter : 170 mm
Spindle Nose : MT-4
Spindle Travel : 250 mm
No. of Spindle Speed : 8
Spindle Speed (RPM) : 88–2600
Diameter of Ram : 78 mm
WORKING RANGE :
Max. Drilling Radius : 980 mm
Dist. from Spindle to Base : 850/250 mm (Max/Min)
Dist. from Column to Spindle : 905/385 mm
ELECTRICAL :
Drilling Head Motor (1440 RPM) : 2 H.P.
Lifting Arm Motor (1440 RPM) : 0.5 H.P.
V-Belt Section : B-40 & B-23
GENERAL SPECIFICATION :
Machine Measurement : 1350 x 660 x 2080 mm
Size of Box Table : 300 x 300 x 385 mm
Approx Weight : 900 Kg
| GST | 24AACFY1099B1ZD |
| Year of Establishment | 1991 |
| Number of Employees | 1 - 50 |
| Turnover | 100000000 |
| Legal Status | Partnership |
if you are interested, please fill the below details:
